Description
|
Frame
|
4 channels, hard pressed extruded aluminium alloy 6061/T6. (Surface anodized finish. Anti rust.)
|
|||
|
Roof Cover
|
Opaque(or transparent), water proof, 850g/m². Flame retardant.PVC-coated Polyester.
|
|||
|
Side Wall
|
1) 650g/m² PVC-coated Polyester 2) glass wall
3) ABS wall |
|||
|
Wind Resistance
|
80~140km/h
|
|||
|
Snow Load
|
25kg/sqm
|
|||
|
Fixing Solution
|
Ground anchor, expandable bolt, weight plate, etc.
|
|||
|
Service Life
|
More than 15 years
|
|||
|
Applicable temperature range
|
-30 degree Celsius ~ +70 degree Celsius
|
|||
|
Ground Situation
|
Grassland,earth land,asphalt,cement ground,marble,etc
|
|||
|
Connectors
|
Hot-dip galvanized twin plate;expansion bolts to fix tent
|
|||
Size:
|
Span Width
|
Length
|
Eave Height
|
Ridge Height
|
Bay Spacing
|
Main Profile Size
|
|
20m
|
Unlimited
|
4m/5m
|
10m
|
5m
|
200x120x4x4.5mm
|
|
25m
|
12.5m
|
250x120x4x6mm
|
|||
|
30m
|
15m
|
300x120x5/7mm
|
|||
|
35m
|
17.5m
|
300x120x5/7mm
|
|||
|
40m
|
20m
|
300x120x5x7mm 350x120x5x7mm
|
